Grimme GF 200

The rotary tiller type GF 200, mounted in the rear or in the front of the tractor, is suitable as a full width tiller for an optimum seedbed preparation for the cultivation of various vegetables and potatoes. An ideal prepared seedbed is the prerequisite for optimum development of the seed resp. planting tubers. Through intensive soil cultivation, root crop ground preparation is perfectly achieved so that undisturbed growth of the crop can be guaranteed.

For conventional hilling (in a second working step) the rotary tiller GF 200 can be modified to be used as a rotary hiller with rear attachment at the tractor. The machine can be converted from independent rows to a full width tiller with a few simple steps. When attached to the front of the tractor, the GF 200 can be perfectly combined with a potato planter at the rear side of the tractor. The drive is designed for a tractor output up to 165 HP.

Highlights

The GF 200 rotary tiller is designed to perform effectively even in very stony soils, thanks to its extra-stable rotor shaft spikes that ensure durability and consistent performance. It also supports combined plant protection through the GRIMME TS 420 tank system, allowing authorized liquid chemicals to be applied directly onto seed potatoes or into the furrow during operation.

The machine ensures precise and even working depth with its large carriage roller, delivering uniform soil preparation. Additionally, the ridge shaper with integrated formers prevents loosened soil from being compacted by tractor wheels, maintaining optimal soil structure for crop development.

With its front attachment capability, the GF 200 can be ideally combined with trailed or mounted 2-row potato planters, making it especially suitable for short headlands and smaller fields. Its intensive soil cultivation creates the ideal seedbed, ensuring proper root crop development and undisturbed plant growth.

Standard equipment

GF 200 front attachment:

• working width 1.50 m (row width 75 cm), full width tiller
• rotor shaft with 64 tines with additional welded wear protection (50 x 12 mm)
• Height adjustable carrying roller in front of the rotary tiller
• three-point linkage Cat. 2
• Walterscheid drive shaft with friction clutch and 6 grooves
• gearbox, 350 rpm, single drive for max. 165 HP
• side gearbox with spur gears in it´s own housing
• ridge shaper with centre shaper for ridge pre-shaping

GF 200 rear attachment:

• row width 75 cm, rotary hiller
• rotor shaft with 32 tines with additional welded wear protection (50 x 12 mm)
• 2 infinitely height adjustable support wheels for depth control
• shaping board for bulbous ridges
• shaping board pressure adjustment via springs
• Manual levelling adjustment of the shaping board via spindles
• three-point linkage Cat. 2
• Walterscheid drive shaft with friction clutch and 6 grooves
• gearbox, 350 rpm, single drive for max. 165 HP
• side gearbox with spur gears in it´s own housing
