The V-Stack 618 is a high-performance palletizing solution designed for medium-sized packers requiring precision and flexibility. Its four-sided, closed stacking chamber interlocks each layer, ensuring uniform, stable, and high-quality pallet stacks. Fully automated controls allow the machine to handle bags ranging from 2.5 to 50 kilograms, eliminating the need for manual stacking and improving operational efficiency.
Products are fed through stable conveyors with automatic buffering, maintaining a continuous and reliable flow. Inside the machine, a high-precision manipulator equipped with centering flaps and formation doors accurately positions each layer. The system also features a user-friendly touchscreen, intelligent software, and remote access technology, enabling efficient monitoring and immediate service support from any location.
Specifications
Model Features
- User-friendly touchscreen interface
- Easy configuration of stacking patterns
- Remote access capability
- High and low infeed level options
- Automatic stack/support transport
- Vertical compression system
- Four-sided stack enclosure
- Entrance protection Access platform
Performance
- Up to 5 units per layer: 920 units/hour
- Up to 13 units per layer: 975 units/hour
Dimensions & Capacity
- Maximum layer size: 1600 × 1250 mm
- Maximum package weight: 50 kg
- Minimum product size: 350 × 220 × 50 mm
- Maximum product size: 880 × 590 × 325 mm
Benefits
- Consistent and highly stable pallet stacks
- Space-efficient design
- Low energy consumption
- Minimal maintenance requirements
- Fast return on investment (ROI)
Popular Options & Add-ons
- Customizable stacking chamber and formation collar
- Soft landing system on formation doors
- Electrically adjustable formation collar
- Integrated sheet and interlayer dispenser
- Combi manipulator for bags, boxes, and crates
- Larger manipulator for handling bags up to 50 kg
- Stand-alone wrapping system
- External start for new pallet operations
