The GRIMME FA 200 is a versatile 2-row front cultivator designed for under-root fertilisation. It can be equipped with a 650-litre fertiliser bunker, promoting even root development, while its closed feed system prevents blockages from dust or lumps.
For bed cultivation, traction wheels ensure precise fertiliser application, while in conventional systems the spreader is driven by a cage roller. The TS 420 tank system enables liquid seed dressing directly onto tubers or into the furrow.
Used as a front cultivator with ridging bodies, it reduces soil compaction by the tractor. When combined with a planter, it allows multiple operations in one pass, improving efficiency and reducing field traffic.
Highlights
The GRIMME FA 200 ensures protection against aggressive fertiliser dust with a fully enclosed supply system, preventing contamination and blockages.
Precise fertiliser application is achieved through sprocket-driven dosing, while the 2.2 m wide fertiliser box allows easy and convenient filling.
By combining a front-mounted fertiliser unit with a rear-mounted planter, it enables under-root fertilisation, liquid seed dressing, and furrow treatment in a single efficient pass.
Standard equipment
Front fertiliser
- Mounting frame with stainless steel hopper
- Tank capacity 650 l
- Foldable canvas cover
- Screen Level indicator
- Mechanical drive of the fertiliser box via carriage roller
- Carriage roller with integrated brake
- Infinitely adjustable depth guidance by use of a carriage roller with a width of 1600 mm and a diameter of 450 mm
- Insensitive auger application
- 4 closed tine outlets without dust formation
- Adjustment of the fertiliser application rates via different pairs of gear wheels
Front cultivator
- Mounting frame with 3 spring loaded ridging bodies
- Infinitely adjustable depth guidance by use of a carriage roller with a width of 1600 mm and a diameter of 450 mm
(Click to enlarge)
Grimme FA 200 Technical specifications
