Vanmark Compact Hydrocutter

Vanmark Compact Hydrocutter

Descripción
Vanmark’s hydrocutting machines cut food products into various shapes using water powered by a pump loop to transport and accelerate it through a fixed array of stainless-steel cutting blades.

The Compact Hydrocutter System provides the quality and durability Vanmark is known for in an easy-to-install, compact integrated system. Its user-friendly, flexible operation and sanitary design make the Compact Hydrocutter System essential for processors growing their operations or running seasonal and specialty products.

  • Flexible throughput – 1,000 to 50,000 pounds (453-22,679 kg) per hour
  • Frame mounted on three interlocking skids
  • Complete system includes a pump, cutter, decelerator, and dewatering conveyor
  • Stainless steel hydro tubes available in a variety of sizes
  • Designed for quick changeouts with valves to isolate the cutter assembly

(Click picture to watch video)Vanmark Hydrocutting Equipment

Vanmark Hydrocutting Equipment

Specifications

  • System Dimensions: 230" L x 80" W x 92" H (5842 x 2032 x 2337mm)
Product Size:

  • Diameter - up to 4-7.25” (102-184 mm)
  • Length - up to 6-12” (152-305 mm)
Pump Size*:

  • 6, 8, or 10" pump assembly
  • *Dependent on product size
  • Water Capacity: 82 gallons (310 L)
  • Electrical: 230-460 VAC, 3 Phase (other voltages available)
  • Motor: 1-5 HP
Features

  • 304 or 316 stainless steel construction
  • Stainless steel hydrotubes
  • Skid-mounted with +/- 2" (50 mm) adjustable feet
  • Flow meters hold consistent cut speeds
  • "Sleeve" cutter inlet
  • Integrated decelerator and dewatering conveyor
Options

  • Integrated control system
  • Additional pump sizes to accommodate larger products
Fabricante
Vanmark Equipment LLC
Vanmark Equipment LLC

Vanmark es un fabricante líder de equipos de procesamiento industrial de papas y productos, trabajando con clientes para producir alimentos seguros y de alta calidad que ellos conocen y aman comer.
